China Max Pressure 30Mpa Spring Driven Hydraulic Hose Reel With 1/4" Dual Hose Auto Reacting Reel for Aerial Work Vehicle wholesale

Max Pressure 30Mpa Spring Driven Hydraulic Hose Reel With 1/4" Dual Hose Auto Reacting Reel for Aerial Work Vehicle

Name: Max Pressure 30Mpa Spring Driven Hydraulic Hose Reel With 14 Dual Hose Auto Reacting Reel for Aerial Work Vehicle
Brand: HUATE
Price: 950 USD

Ask Latest Price

Video Channel

Place of Origin :Hubei, China

Brand Name :HUATE

Model Number :HT.GKC

Price :$950/sets 1-9 sets

Packaging Details :Wooden box

Delivery Time :7-30 days

Payment Terms :T/T

Working Voltage :/

Flow Rate :/

Warranty :12 Months

Certificate :/

Type :Standard

Product Name :Electric Dual Hydraulic Hose Reels High Pressure Spring Driven

Suit for :Aerial Work Vehicle,Forklift,off-Road Vehicle

Material :Carbon Steel

Max Pressure :30Mpa

Driving method :Spring Dirven

Oil Channel :Dual

Oil pipe size :1/4 inch

Package :Carbon

Tube Retracting method :Automatic retracting

Use :Oil

Application :Aerial Work Vehicle,Forklift,off-Road Vehicle

MOQ :1

Supply Ability :Meet large-scale orders

Contact Now

Add to Cart

View Product Description

Products Description

Hydraulic hose reels with factory-lubricated one-piece power spring makes installation safer and maintenance easier. Ideal for kinds of Cranes and forklifts. Stainless latch parts are available as a standard option. All of our products can be customized with stainless steel. We also accept non-standard customization. ● Heavy duty. All-steel construction. ● For two single hoses with bigger diameter and bigger usable hose length, with additional middle flange ● Available in Left or Right version ● Fixation by mounting flange ● Self winding by permanent spring force ● Full flow shaft swivels. ● Superior performance：Swivel and reel ball bearings reduce torque load on power spring for smooth retraction and durability. ● Corrosion resistant: Sealed bearings prevent contamination and minimize maintenance. ● Easy installation and maintenance：Factory lubricated one-piece power spring cassette make installation safer and maintenance easier. ● Adjustable and Versatile：Guide arm adjust to wall,floor,vehicle, overhead positions. Narrow design allows for maximum use of available space.

Weight	41 kg-49kg
Hose I.D.	1/4"
Hose O.D.	1/2"
Hose Length	15.5-25M Customized
Pressure	30 Mpa
Hose End	3/8" NPT(M)
Inlet	3/8" NPT(M)
Reel Outlet	M14 x 1.5 H NPT(M)
Hose Included	Yes
Operate Temperature	-40 to 80 Degree Celsius
